Cat 247B3 Compact track loaders research
Cat 247B3 Compact track loaders Technical specifications
General
Engine model
Cat C2.2 T
Operating weight
3,173 kg
Max speed forward
11.27 kph
Max horizontal reach
1.35 m
Engine
Displacement
2195 cu cm
Gross power
46.23 kw
Alternator supplied amperage
85 Amh
Operating voltage
12 V
Net power
41.76 kw
Bore
8.38 cm
Stroke
9.91 cm
Transport dimensions
Transport width
1 m
Operational specifications
Tipping angle
4,299 degrees
Undercarriage
Ground contact area
29005.17 cu cm
Tracks length
1 m
Ground pressure
0.28 bar
Dimensions
Ground clearance
0.25 m
Width over tracks
1.68 m
Max height to hinge pin
22.1 cm
Turning radius
2.1 m
Hydraulic system
Pump flow cap
61.32 lpm
Relief valve pressure
229.94 bar
Pump type
Standard
Loader
Loader lift cap
975.04 kg
Loader dump height
2.16 m
Loader dump reach
0.64 m
Tipping load
1950.45 kg
Service refill capacities
Cooling fluid cap
10.22 liters
Fuel cap
65.1 liters
Hydraulic fluid cap
55.26 liters
Engine crankcase
9.84 liters
Refill capacities
Engine oil cap
10.22 liters
Operating specifications
Dump angle
40 degrees
Rack back angle
82 degrees
Angle of departure
41 degrees
