The Manitou 160 is a diesel-powered articulated boom lift built for outdoor access and maintenance work on construction and industrial sites. With a 16.02 m working height, solid horizontal reach, and simple mechanical design, it offers a budget-friendly alternative to newer boom lifts in its class.
max working height 16.02 m
horizontal reach 8.3 m
unrestricted platform capacity 230 kg
Perkins diesel engine, 33.55 kW
continuous swing 360°
operating weight 7,450 kg
Manitou 160 Technical specifications
Dimensions
Axle Oscillation
0.15 m
Ground clearance
0.36 cm
Overall Length
6.68 m
Overall Width
2.32 m
Stowed height
2.37 m
Turning radius
3.91 m
Wheelbase
2 m
Performance
Drive Speed - Platform Lowered
5 kph
Platform Capacity - Unrestricted
230 kg
General
Engine model
Perkins 404C-22
Fuel type
Diesel
Gradeability
24 º
Max horizontal reach
8.3 mm
Max working height
16.02 m
Operating voltage
12 V
Operating weight
7,450 kg
Platform rotation
90 º
Tire size
15-19.5
Service refill capacities
Fuel cap
52 liter
Hydraulic fluid cap
54 liter
Engine
Gross power
33.55 kw
Platform
Platform Dimension A
1.8 m
Platform Dimension B
0.8 m
Operating specifications
Swing
360 º
Swing type
Continuous
Tire Type
Foam-filled
Manitou 160 expert review
:quality(50)/55272/8c2d1d6b-e9a4-40d8-9825-964e2a331151.webp)
Overview
The Manitou 160 is an articulated boom lift designed for outdoor maintenance and construction access where simplicity and reliability matter.
Efficiency
The Manitou 160 delivers consistent performance for access and maintenance tasks without unnecessary system complexity.
Platform & Controls
A 230 kg platform capacity and straightforward controls support safe, predictable operation.
In Comparison
It matches the JLG E300 for reach while offering simpler mechanics, and undercuts the Sinoboom AB15 on cost.
Verdict
Rated 5 stars, the Manitou 160 is a cost-effective boom lift for outdoor access work in smaller fleets.
Manitou 160 owner rating
2004-2011
Overall rating
Based on 3 ratings
4.0
4.3
4.7
4.7
4.7
67 %
33 %
0 %
0 %
0 %
4.0
4.0
5.0
5.0
5.0
