New holland C175 Compact track loaders tech specs

makana img
video play button
Video[1]
Interior [2]
Exterior [4]
Attachments [2]
2007-2012
2,212.26 cu cm Displacement
44.74 kw Gross power
3.72 m Loader dump height
0.79 m Loader dump reach
997.9 kg Lifting capacity
3,417 kg Operating weight

A compact track loader designed for landscaping, construction, and material handling work, the New Holland C175 combines 41.76 kilowatt net engine power with a 997.9 kg rated lifting capacity and stable rubber-track undercarriage. With a 0.54 cu m bucket, compact 3.29 m overall length, and low ground pressure of 0.37 bar, the machine is well suited for site preparation, grading, and material movement on soft ground.

Net power 41.76 kilowatt

Maximum torque 173.54 Nm

Rated lifting capacity 997.9 kg

Bucket capacity 0.54 cu m

Operating weight 3,417 kg

Track width 32 cm

Ground pressure 0.37 bar

Fuel tank capacity 54.5 liters

Makana rating

Owner rating

 | 3

Market average

AED 118,000

Starting from

AED 60,600

New holland C175 Technical specifications

Engine

Alternator supplied amperage

55 Amh

Aspiration

Turbocharged

Gross power

44.74 kw

Net power

41.76 kw

Number of cylinders

4

Power measured @

2,900 rpm

Torque measured @

1,700 rpm

Loader

Breakout force

1955.89 kg

Loader dump height

3.72 m

Loader dump reach

0.79 m

General

Bucket capacity

0.54 cu m

Displacement

2212.26 cu cm

Engine model

N844LT

Lifting capacity

997.9 kg

Max speed forward

11.91 kph

Max torque

173.54 Nm

Operating voltage

12 V

Operating weight

3,417 kg

Service refill capacities

Cooling fluid cap

17.03 liter

Fuel cap

54.5 liter

Hydraulic fluid cap

32.55 liter

Refill capacities

Engine oil cap

7.95 liter

Dimensions

Ground clearance

0.2 m

Height - top of cab

1.92 m

Length with bucket

3.29 m

Turning radius

1.99 m

Width over tracks

1.83 m

Undercarriage

Ground pressure

0.37 bar

Number of track rollers per side

3

Track gauge

1.49 m

Track length

1.46 m

Track width

32 cm

Hydraulic system

Pump flow cap

65.1 lpm

Pump type

Gear pump

Relief valve pressure

179.26 bar

Operating specifications

Rack back angle

63 º

View more
Download datasheets
OEM product brochure

New holland C175 expert review

Reviewed by Jed H. on March 10, 2026

Overview

The New Holland C175 (2007–2012) is a compact track loader designed for landscaping, grading, and construction work. It delivers 41.76 kilowatt engine power, nearly 1,000 kg lifting capacity, and stable performance on soft ground.

Expert rating: 3 stars

Pros Stable tracked undercarriage with low ground pressure for soft terrain.
Cons Limited lifting capacity compared with larger track loaders.

Performance & Efficiency

The turbocharged N844LT engine produces 41.76 kilowatt and around 173 Nm of torque, providing reliable power for landscaping and site preparation work.

In Comparison

Cat 247: Durable compact track loader with strong dealer support.
Cat 257: Larger machine with higher lifting capacity.
New Holland C175: Compact and lightweight option suited for small job sites.

Final Verdict

Rated 3 stars, the New Holland C175 offers practical compact track loader performance within the AED 60,600–118,000 range.

Show less

New holland C175 owner rating

New holland C175 Compact track loaders [2007-2012]

2007-2012

Overall rating

Based on 3 ratings

4.3
performance

4.3

comfort

4.3

fuel efficiency

4.7

safety

4.7

features

4.7

5 stars

33 %

4 stars

67 %

3 stars

0 %

2 stars

0 %

1 stars

0 %

Pros
Tracks provide excellent traction on soft ground and uneven terrain.
Cons
Lifting capacity is limited for heavier material handling jobs.
performance

4.0

comfort

5.0

fuel efficiency

4.0

safety

5.0

features

4.0

Valuation

Last 12 month
2007

New holland C175 similar models

Highlight differences
New holland C175
Cat 247
Cat 257
Engine
Alternator supplied amperage 55 Amh
Alternator supplied amperage -
Alternator supplied amperage -
Aspiration Turbocharged
Aspiration -
Aspiration Turbocharged
Gross power 44.74 kw
Gross power 43.25 kw
Gross power 46.98 kw
Net power 41.76 kw
Net power 40.27 kw
Net power 44 kw
Number of cylinders 4
Number of cylinders 4
Number of cylinders 4
Power measured @ 2,900 rpm
Power measured @ 2,600 rpm
Power measured @ 2,600 rpm
Torque measured @ 1,700 rpm
Torque measured @ -
Torque measured @ -
Bore -
Bore 9.91 cm
Bore 9.91 cm
Stroke -
Stroke 10.16 cm
Stroke 10.16 cm
Years 2007-2012
Years 2004-2008
Years 2014-2019
Market Average AED 118,000
Market Average AED 145,000
Market Average AED 186,000
Price AED 60,600
Price AED 130,000
Price AED 147,000
Loader
Breakout force 1,955.89 kg
Breakout force -
Breakout force -
Loader dump height 3.72 m
Loader dump height 2.1 m
Loader dump height 2.29 m
Loader dump reach 0.79 m
Loader dump reach 0.64 m
Loader dump reach 0.82 m
Breakout force - lift cylinder -
Breakout force - lift cylinder 1,365.77 kg
Breakout force - lift cylinder 1,583.04 kg
Breakout force - tilt cylinder -
Breakout force - tilt cylinder 1,603.9 kg
Breakout force - tilt cylinder 1,602.09 kg
General
Bucket capacity 0.54 cu m
Bucket capacity 0.38 cu m
Bucket capacity 0.46 cu m
Displacement 2,212.26 cu cm
Displacement 2,998.84 cu cm
Displacement 2,998.84 cu cm
Engine model N844LT
Engine model Cat 3034 naturally aspirated
Engine model Cat 3034 naturally aspirated
Lifting capacity 997.9 kg
Lifting capacity 952.55 kg
Lifting capacity 1,065.94 kg
Max speed forward 11.91 kph
Max speed forward 12.07 kph
Max speed forward 12.07 kph
Max torque 173.54 Nm
Max torque -
Max torque -
Operating voltage 12 V
Operating voltage -
Operating voltage -
Operating weight 3,417 kg
Operating weight 3,023 kg
Operating weight 3,460 kg
Tipping load -
Tipping load 1,753 kg
Tipping load 2,091 kg
Service refill capacities
Cooling fluid cap 17.03 liter
Cooling fluid cap 9.84 liter
Cooling fluid cap 9.84 liter
Fuel cap 54.5 liter
Fuel cap 64.35 liter
Fuel cap 90.08 liter
Hydraulic fluid cap 32.55 liter
Hydraulic fluid cap 55.26 liter
Hydraulic fluid cap 55.26 liter
Engine crankcase -
Engine crankcase 6.81 liter
Engine crankcase 6.81 liter
Refill capacities
Engine oil cap 7.95 liter
Engine oil cap -
Engine oil cap -
Dimensions
Ground clearance 0.2 m
Ground clearance 0.27 m
Ground clearance 0.26 m
Height - top of cab 1.92 m
Height - top of cab 2.01 m
Height - top of cab 2.04 m
Length with bucket 3.29 m
Length with bucket 3.32 m
Length with bucket 3.54 m
Turning radius 1.99 m
Turning radius 2.16 m
Turning radius 2.29 m
Width over tracks 1.83 m
Width over tracks 1.68 m
Width over tracks 1.68 m
Length without Bucket -
Length without Bucket 2.53 m
Length without Bucket 2.71 m
Undercarriage
Ground pressure 0.37 bar
Ground pressure 0.26 bar
Ground pressure 0.3 bar
Number of track rollers per side 3
Number of track rollers per side -
Number of track rollers per side -
Track gauge 1.49 m
Track gauge -
Track gauge -
Track length 1.46 m
Track length 1.52 m
Track length 1.52 m
Track width 32 cm
Track width 38.1 cm
Track width 38.1 cm
Ground contact area -
Ground contact area 29,005.17 cu cm
Ground contact area 29,005.17 cu cm
Hydraulic system
Pump flow cap 65.1 lpm
Pump flow cap 54.5 lpm
Pump flow cap 57.53 lpm
Pump type Gear pump
Pump type -
Pump type -
Relief valve pressure 179.26 bar
Relief valve pressure -
Relief valve pressure -
Operating specifications
Rack back angle 63 º
Rack back angle 37 º
Rack back angle 44 º
