New holland 575 Backhoe loaders tech specs

Alternator supplied amperage

70 Amh

Bore

11.43 cm

Engine make

New Holland

Gross power

67.11 kw

Max torque

363.35 Nm

Net power

63.39 kw

Number of cylinders

4

Stroke

12.7 cm

Torque measured @

1,400 rpm

Backhoe digging depth

4.42 m

Backhoe dump height

4.08 m

Backhoe reach from swivel

5.64 m

Breakout force

6010.11 kg

Loader dump height

2.71 m

Loader dump reach

0.79 m

Bucket digging force

5266.21 kg

Bucket width

223 cm

Engine model

BSD 450T

Max speed forward

32.35 kph

Operating voltage

12 V

Operating weight

7,259 kg

Transmission type

Powershuttle

Cooling fluid cap

23.85 liter

Fuel cap

105.98 liter

Hydraulic fluid cap

137.02 liter

Engine oil cap

17.03 liter

Extended backhoe digging depth

5.64 m

Extended backhoe dump height

4.42 m

Extended backhoe reach from swivel

6.77 m

Front tires size (2WD)

11L-16 / 12-16.5

Rear tires size

19.5Lx24

Ground clearance

0.46 m

Height - top of cab

2.87 m

Overall Length

7.13 m

Overall Width

2.29 m

Wheelbase

2.19 m

Max speed reverse

40.23 kph

Number of forward gears

4

Number of reverse gears

4

Pump flow cap

143.83 lpm

Pump type

Open center

Relief valve pressure

196.5 bar
