Mecalac TLB9 Backhoe loaders tech specs
:quality(50)/75714/conversions/8cdaddaa-4ba3-41a8-b4e3-95d6c87f98ac-thumb.webp)
Video[1]
:quality(50)/75705/conversions/944f541b-d46f-4d64-8c4a-775bf9620b05-thumb.webp)
Interior [3]
:quality(50)/75708/conversions/7a771a4f-f514-4d72-a23d-90de809e6b58-thumb.webp)
Exterior [4]
:quality(50)/75712/conversions/a9d52824-703b-4c16-a738-bb72bb18daf8-thumb.webp)
Attachments [2]
2017-2025
4.39 m Backhoe digging depth
1.07 cu m Bucket capacity
140.05 liter Fuel cap
400.1 Nm Max torque
65.77 kw Net power
8,230 kg Operating weight
Makana rating
Market average
AED 260,000Starting from
AED 170,000Mecalac TLB9 Technical specifications
Backhoe
Backhoe digging depth
4.39 m
Backhoe dump height
3.38 m
Backhoe reach from swivel
5.73 m
General
Bucket capacity
1.07 cu m
Engine model
E44TA
Operating voltage
12 V
Operating weight
8,230 kg
Service refill capacities
Cooling fluid cap
16.28 liter
Front axle fluid capacity
9.84 liter
Fuel cap
140.05 liter
Hydraulic fluid cap
92.35 liter
Rear axle fluid capacity
15.52 liter
Operating specifications
Dump angle
45 º
Engine
Gross power
70.02 kw
Max torque
400.1 Nm
Net power
65.77 kw
Number of cylinders
4
Power measured @
2,200 rpm
Torque measured @
1,400 rpm
Transmission
Number of forward gears
4
Number of reverse gears
3
Hydraulic system
Pump flow cap
80.24 lpm
Relief valve pressure
250.41 bar
Download datasheets
Mecalac TLB9 similar models
Highlight differences
Backhoe digging depth
Backhoe digging depth 4.39 m
Backhoe digging depth 5 m
Backhoe digging depth 4.42 m
Backhoe dump height
Backhoe dump height 3.38 m
Backhoe dump height 3.81 m
Backhoe dump height 3.6 m
Backhoe reach from swivel
Backhoe reach from swivel 5.73 m
Backhoe reach from swivel 7.19 m
Backhoe reach from swivel 5.7 m
Years
Years 2017-2025
Years 2007-2012
Years 2017-2025
Market Average
Market Average AED 260,000
Market Average AED 200,000
Market Average AED 230,000
Price
Price AED 170,000
Price AED 120,000
Price AED 150,000
Bucket capacity
Bucket capacity 1.07 cu m
Bucket capacity -
Bucket capacity 0.28 cu m
Engine model
Engine model E44TA
Engine model 1104C44 T
Engine model TCD 3.6 L4
Operating voltage
Operating voltage 12 V
Operating voltage -
Operating voltage 12 V
Operating weight
Operating weight 8,230 kg
Operating weight 7,460 kg
Operating weight 7,320 kg
Lifting capacity
Lifting capacity -
Lifting capacity 2,100.04 kg
Lifting capacity 3,758.92 kg
Max speed forward
Max speed forward -
Max speed forward 25.11 kph
Max speed forward 38.62 kph
Transmission type
Transmission type -
Transmission type torque converter
Transmission type -
Cooling fluid cap
Cooling fluid cap 16.28 liter
Cooling fluid cap -
Cooling fluid cap 17.03 liter
Front axle fluid capacity
Front axle fluid capacity 9.84 liter
Front axle fluid capacity -
Front axle fluid capacity 7.19 liter
Fuel cap
Fuel cap 140.05 liter
Fuel cap 150.26 liter
Fuel cap 140.05 liter
Hydraulic fluid cap
Hydraulic fluid cap 92.35 liter
Hydraulic fluid cap -
Hydraulic fluid cap -
Rear axle fluid capacity
Rear axle fluid capacity 15.52 liter
Rear axle fluid capacity -
Rear axle fluid capacity 17.41 liter
Dump angle
Dump angle 45 º
Dump angle -
Dump angle 45 º
Gross power
Gross power 70.02 kw
Gross power 74.57 kw
Gross power 55.18 kw
Max torque
Max torque 400.1 Nm
Max torque -
Max torque -
Net power
Net power 65.77 kw
Net power -
Net power 52.13 kw
Number of cylinders
Number of cylinders 4
Number of cylinders -
Number of cylinders 4
Power measured @
Power measured @ 2,200 rpm
Power measured @ -
Power measured @ -
Torque measured @
Torque measured @ 1,400 rpm
Torque measured @ -
Torque measured @ 1,300 rpm
Displacement
Displacement -
Displacement -
Displacement 3,600.25 cu cm
Number of forward gears
Number of forward gears 4
Number of forward gears 4
Number of forward gears 4
Number of reverse gears
Number of reverse gears 3
Number of reverse gears 4
Number of reverse gears 4
Max speed reverse
Max speed reverse -
Max speed reverse 25.11 kph
Max speed reverse -
Pump flow cap
Pump flow cap 80.24 lpm
Pump flow cap 184.33 lpm
Pump flow cap 83.27 lpm
Relief valve pressure
Relief valve pressure 250.41 bar
Relief valve pressure -
Relief valve pressure 250 bar
Pump type
Pump type -
Pump type Gear pump
Pump type -
Bucket digging force
Bucket digging force -
Bucket digging force 6,424.01 kg
Bucket digging force -
Loader dump height
Loader dump height -
Loader dump height 5.24 m
Loader dump height -
Breakout force
Breakout force -
Breakout force -
Breakout force 4,282.82 kg
Overall Length
Overall Length -
Overall Length 6.98 m
Overall Length -
Overall Width
Overall Width -
Overall Width 2.5 m
Overall Width -
