Mecalac TA1 Dumpers tech specs
:quality(50)/72311/5439ddfb-f6ec-40d0-ae6c-6d6736579e80.png)
:quality(50)/71794/conversions/45c3d167-4f9c-40fd-b52d-70a9bf79129c-webp.webp)
:quality(50)/71786/conversions/28a506b5-57b0-4751-b277-fb89b991d981-webp.webp)
:quality(50)/71792/conversions/e64ab0b1-cb99-4994-944d-cadca2371244-webp.webp)
:quality(50)/72313/conversions/86ad9cc2-a6ae-47e4-9664-84e89c60b281-webp.webp)
A compact, site-friendly dumper built for tight access and controlled material handling, the Mecalac TA1 combines 4WD traction with a front elevation / high-discharge skip for efficient loading and unloading on congested jobsites. Powered by a Kubota D1005 engine producing 17.5 kilo watt, it targets utility work, landscaping, and urban construction where maneuverability and visibility matter most.
Payload 1,000 kg
Engine power 17.5 kilo watt
Heaped hopper capacity 0.54 cu m
Drive type 4WD
Hydrostatic transmission and braking on all wheels
Max speed 11 km/h
Compact turning radius 4.6 m
Mecalac TA1 Technical specifications
General
Engine model
Kubota D1005
Drive type
4WD
Gradeability
20 %
Tire size
255/75 x 15.3 (8BR)
Max speed forward
11 kph
Transmission type
hydrostatic transmission
Payload
1,000 kg
Engine
Gross power
17.5 kw
Max torque
56 Nm
Number of cylinders
3
Emissions
EU Stage V/U.S. EPA Tier 4 Final
Dimensions
Turning radius
4.6 m
Hydraulic system
Pump flow cap
29 lpm
Relief valve pressure
152 bar
Pump type
Gear pump
Service refill capacities
Fuel cap
35 liter
Hydraulic fluid cap
25 liter
Operating specifications
Brake system
Hydrostatic dynamic on all wheels
Exterior sound
101 dB(A) Sound Power Level (LWAd)
Body type
Front Elevation / High Discharge
Empty weight
1340 kg
Heaped hopper cap
0.54 cu m
Mecalac TA1 expert review
:quality(50)/60952/a25e1d76-5098-4ef7-a6f5-fe8bc1dffd1a.jpeg)
Overview
The Mecalac TA1 (2017–2020) is a compact 1-ton dumper designed for confined jobsites. With 4WD, hydrostatic transmission, and a high-discharge skip, it excels in urban and utility applications.
Expert rating: 5 stars
Performance & Efficiency
The 17.5 kilo watt engine and 29 lpm hydraulic flow deliver controlled movement and low fuel consumption for daily site use.
In Comparison
Wacker Neuson 6001: Larger capacity but less compact.
Ausa D1000: Similar class with simpler discharge.
Mecalac TA1: Superior maneuverability and unloading control.
Final Verdict
Rated 5 stars, the Mecalac TA1 is a reliable compact dumper in the AED 45,000–76,000 range.
Mecalac TA1 owner rating
2017-2020
Overall rating
Based on 3 ratings
4.3
4.7
5.0
4.7
4.3
33 %
67 %
0 %
0 %
0 %
4.0
4.0
5.0
5.0
4.0
