The Haulotte HA16 SPX is a solid diesel-powered articulating boom that packs a 16 m working height, 9.1 m horizontal reach, and a 230 kg platform capacity into a rugged, zero-tail-swing body. Compact, capable, and built to stay functional when the rest stalls.
Working / Platform Height: ~16.0 m / ~14.0 m
Horizontal Reach: ~9.1 m
Capacity: 230 kg (2-person)
Stowed Dimensions: ~6.65 m (L) × 2.3 m (W) × 2.2 m (H)
Weight: ~6,700 kg
Drive & Gradeability: 4×4 diesel, ~1.5–5.5 km/h travel, ~40–45 % gradeability
Platform: ~1.8 m × 0.8 m, 180° rotation, 140° jib articulation ±70°
Other Highlights: Zero tailswing, 360° turntable, soft proportional controls, robust Deutz ~42 hp diesel engine, ~45 s lift time
Haulotte HA16 Technical specifications
Service refill capacities
Fuel cap
55.26 liter
Hydraulic fluid cap
100.3 liter
General
Fuel type
Diesel
Max horizontal reach
9110 mm
Max working height
16 m
Operating weight
6,850 kg
Platform rotation
180 º
Tire size
350-14-17.5
Engine
Gross power
31.02 kw
Dimensions
Ground clearance
38.1 cm
Overall Length
5.56 m
Overall Width
2.26 m
Stowed height
2.23 m
Turning radius
4.02 m
Wheelbase
2.01 m
Operating specifications
Raise time
45 seconds
Tire Type
foam filled
Performance
Platform Capacity - Unrestricted
230.02 kg
Drive Speed - Platform Lowered
5.63 kph
Platform
Platform Dimension B
1.81 m
Platform Dimension A
0.81 m
Haulotte HA16 expert review
Overview
Go narrow, reach high, keep going—engineered to last with smart simplicity.
Rugged, reliable, easy to serve.
Diesel means fuel and emissions to manage.
Performance & Efficiency
Fast on the lift, smooth on the drive, low on maintenance—made to run.
Verdict
Haulotte HA16 SPX delivers height, performance, and dependability—straight and sturdy.
Haulotte HA16 owner rating
2004-2014
Overall rating
Based on 0 ratings
0 %
100 %
0 %
0 %
0 %
