Takeuchi TL150 Compact track loaders tech specs
:quality(50)/75615/conversions/4baabc79-6284-4da6-9736-db260902af8d-thumb.webp)
Video[1]
:quality(50)/75608/conversions/a3dbc907-bde7-432a-a4e3-a5edf66b920b-thumb.webp)
Interior [2]
:quality(50)/75610/conversions/5b452a22-8671-4ecf-8f42-e08d802de7b8-thumb.webp)
Exterior [4]
:quality(50)/75614/conversions/2334755d-771e-477f-a496-c123e7648d6c-thumb.webp)
Attachments [1]
2000-2009
4,408.13 cu cm Displacement
72.33 kw Gross power
3.23 m Loader dump height
1.01 m Loader dump reach
1,120.37 kg Lifting capacity
4,945 kg Operating weight
Makana rating
Market average
AED 160,000Starting from
AED 57,000Takeuchi TL150 Technical specifications
Engine
Alternator supplied amperage
60 Amh
Displacement
4408.13 cu cm
Gross power
72.33 kw
Max torque
394.54 Nm
Number of cylinders
4
Power measured @
2,200 rpm
Torque measured @
1,400 rpm
Loader
Breakout force
3942.63 kg
Loader dump height
3.23 m
Loader dump reach
1.01 m
Service refill capacities
Cooling fluid cap
15.14 liter
Fuel cap
107.87 liter
Hydraulic fluid cap
63.97 liter
General
Engine model
4TNV106T
Lifting capacity
1120.37 kg
Max speed forward
11.1 kph
Operating voltage
12 V
Operating weight
4,945 kg
Refill capacities
Engine oil cap
14 liter
Dimensions
Ground clearance
0.34 m
Height - top of cab
2.35 m
Length with bucket
3.93 m
Turning radius
1.75 m
Width over tracks
1.86 m
Undercarriage
Ground pressure
0.3 bar
Number of track rollers per side
6
Track length
1.62 m
Track width
45.72 cm
Hydraulic system
Pump flow cap
88.57 lpm
Relief valve pressure
205.87 bar
Operating specifications
Rack back angle
70 º
Download datasheets
Takeuchi TL150 similar models
Highlight differences
Takeuchi TL150
TL150
JCB 215T
215T
JCB 250T
250T
Alternator supplied amperage
Alternator supplied amperage 60 Amh
Alternator supplied amperage 100 Amh
Alternator supplied amperage 95 Amh
Displacement
Displacement 4,408.13 cu cm
Displacement 2,482.65 cu cm
Displacement 4,399.94 cu cm
Gross power
Gross power 72.33 kw
Gross power 55.03 kw
Gross power 55.03 kw
Max torque
Max torque 394.54 Nm
Max torque 300.04 Nm
Max torque 400.1 Nm
Number of cylinders
Number of cylinders 4
Number of cylinders -
Number of cylinders -
Power measured @
Power measured @ 2,200 rpm
Power measured @ 2,400 rpm
Power measured @ 2,400 rpm
Torque measured @
Torque measured @ 1,400 rpm
Torque measured @ 1,200 rpm
Torque measured @ 1,200 rpm
Aspiration
Aspiration -
Aspiration Turbocharged
Aspiration Liquid
Emissions
Emissions -
Emissions EPA-T4F (EU St3B)
Emissions EPA-T4F (EU St3B)
Engine cooling system
Engine cooling system -
Engine cooling system Liquid
Engine cooling system Liquid
Years
Years 2000-2009
Years 2017-2025
Years 2017-2020
Market Average
Market Average AED 160,000
Market Average AED 299,000
Market Average AED 253,000
Price
Price AED 57,000
Price AED 265,000
Price AED 210,000
Breakout force
Breakout force 3,942.63 kg
Breakout force 2,243.02 kg
Breakout force 2,968.04 kg
Loader dump height
Loader dump height 3.23 m
Loader dump height 3.05 m
Loader dump height 2.9 m
Loader dump reach
Loader dump reach 1.01 m
Loader dump reach 1.22 m
Loader dump reach 1.01 m
Loader digging depth
Loader digging depth -
Loader digging depth -
Loader digging depth 1,000 cm
Cooling fluid cap
Cooling fluid cap 15.14 liter
Cooling fluid cap 10.22 liter
Cooling fluid cap 22.33 liter
Fuel cap
Fuel cap 107.87 liter
Fuel cap 98.03 liter
Fuel cap 103.33 liter
Hydraulic fluid cap
Hydraulic fluid cap 63.97 liter
Hydraulic fluid cap 43.53 liter
Hydraulic fluid cap 55.26 liter
Engine model
Engine model 4TNV106T
Engine model Kohler - KDI2504TCR/26A
Engine model EcoMAX TCAE-55
Lifting capacity
Lifting capacity 1,120.37 kg
Lifting capacity 4,127.02 kg
Lifting capacity 4,818.02 kg
Max speed forward
Max speed forward 11.1 kph
Max speed forward 10.14 kph
Max speed forward -
Operating voltage
Operating voltage 12 V
Operating voltage 12 V
Operating voltage 12 V
Operating weight
Operating weight 4,945 kg
Operating weight 4,127 kg
Operating weight 4,818 kg
Bucket capacity
Bucket capacity -
Bucket capacity 0.38 cu m
Bucket capacity 0.46 cu m
Bucket width
Bucket width -
Bucket width 168 cm
Bucket width 190 cm
Engine oil cap
Engine oil cap 14 liter
Engine oil cap 7.57 liter
Engine oil cap 15.14 liter
Ground clearance
Ground clearance 0.34 m
Ground clearance 0.23 m
Ground clearance 0.23 m
Height - top of cab
Height - top of cab 2.35 m
Height - top of cab 2.01 m
Height - top of cab 2.1 m
Length with bucket
Length with bucket 3.93 m
Length with bucket 3.51 m
Length with bucket 3.81 m
Turning radius
Turning radius 1.75 m
Turning radius -
Turning radius -
Width over tracks
Width over tracks 1.86 m
Width over tracks 1.71 m
Width over tracks 1.92 m
Ground pressure
Ground pressure 0.3 bar
Ground pressure -
Ground pressure -
Number of track rollers per side
Number of track rollers per side 6
Number of track rollers per side -
Number of track rollers per side -
Track length
Track length 1.62 m
Track length -
Track length -
Track width
Track width 45.72 cm
Track width -
Track width -
Pump flow cap
Pump flow cap 88.57 lpm
Pump flow cap -
Pump flow cap -
Relief valve pressure
Relief valve pressure 205.87 bar
Relief valve pressure -
Relief valve pressure -
Rack back angle
Rack back angle 70 º
Rack back angle 60 º
Rack back angle 77 º
Angle of departure
Angle of departure -
Angle of departure 27 º
Angle of departure 29 º
Dump angle
Dump angle -
Dump angle -
Dump angle 42 º
