Genie Z-30 Boom lifts tech specs
:quality(50)/76139/conversions/ea2c8c12-ab7c-4cae-a150-ce2cf2bd7cdf-thumb.webp)
Video[1]
:quality(50)/76131/conversions/92092152-f867-4555-b7b6-f97db09845c9-thumb.webp)
Interior [2]
:quality(50)/76133/conversions/b8d4db41-c15e-4fbf-a57f-4e9c11fb6749-thumb.webp)
Exterior [4]
:quality(50)/76137/conversions/150566af-4b52-483f-9275-831336f24b28-thumb.webp)
Attachments [2]
Genie Z-30 technical specifications
Highlight differences
Battery amperage
Battery amperage 350 Amh
Battery amperage 350 Amh
Charger amps
Charger amps 24 Amh
Charger amps 24 Amh
Number of batteries
Number of batteries 8
Number of batteries 8
Years
Years 2001-2019
Years 2001-2019
Market Average
Market Average AED 100,000
Market Average AED 100,000
Price
Price AED 45,000
Price AED 45,000
Ground clearance
Ground clearance 0.09 m
Ground clearance 0.09 m
Stowed height
Stowed height 2.01 m
Stowed height 2.03 m
Overall Length
Overall Length 0.43 m
Overall Length 0.43 m
Overall Width
Overall Width 1.22 m
Overall Width 1.22 m
Turning radius
Turning radius 3.23 m
Turning radius 3.23 m
Wheelbase
Wheelbase 1.62 m
Wheelbase 1.62 m
Boom size
Boom size -
Boom size 8.29 m
Hydraulic fluid cap
Hydraulic fluid cap 15.14 liter
Hydraulic fluid cap 15.14 liter
Platform Dimension B
Platform Dimension B 119.13 cm
Platform Dimension B 119.13 cm
Platform Dimension A
Platform Dimension A 76.2 cm
Platform Dimension A 76.2 cm
Max horizontal reach
Max horizontal reach 6.55 m
Max horizontal reach 6.28 m
Max speed forward
Max speed forward 4.83 kph
Max speed forward 4.83 kph
Max working height
Max working height 11.16 m
Max working height 10.91 m
Operating voltage
Operating voltage 48 V
Operating voltage 48 V
Operating weight
Operating weight 6,427 kg
Operating weight 6,450 kg
Platform rotation
Platform rotation 180 º
Platform rotation 180 º
Tire size
Tire size 22x7x17.75
Tire size 22x7x17.75
Platform Capacity - Unrestricted
Platform Capacity - Unrestricted 227.02 kg
Platform Capacity - Unrestricted 227.02 kg
Tire Type
Tire Type Solid non-marking
Tire Type Solid non-marking
Download datasheets
Genie Z-30 similar models
Highlight differences
:quality(50)/72049/72f0a2e0-f84a-4b8c-8b9b-873a70213c73.png)
:quality(50)/76318/3e0c0ffa-24fd-4fa2-927e-b5f4c294a776.png)
Battery amperage
Battery amperage 350 Amh
Battery amperage -
Battery amperage -
Charger amps
Charger amps 24 Amh
Charger amps -
Charger amps -
Number of batteries
Number of batteries 8
Number of batteries -
Number of batteries -
Gross power
Gross power -
Gross power 36.4 kw
Gross power 35.8 kw
Years
Years 2001-2019
Years 2016-2020
Years 2012-2021
Market Average
Market Average AED 100,000
Market Average AED 220,000
Market Average AED 165,000
Price
Price AED 45,000
Price AED 128,500
Price AED 105,900
Ground clearance
Ground clearance 0.09 m
Ground clearance 31 cm
Ground clearance 37 cm
Stowed height
Stowed height 2.01 m
Stowed height 2.49 m
Stowed height 2.13 mm
Overall Length
Overall Length 0.43 m
Overall Length 8.91 m
Overall Length 6.65 m
Overall Width
Overall Width 1.22 m
Overall Width 2.31 m
Overall Width 2.29 m
Turning radius
Turning radius 3.23 m
Turning radius 4.83 m
Turning radius 4.5 m
Wheelbase
Wheelbase 1.62 m
Wheelbase 2.39 m
Wheelbase 2.03 mm
Axle Oscillation
Axle Oscillation -
Axle Oscillation 0.2 m
Axle Oscillation 0.15 m
Hydraulic fluid cap
Hydraulic fluid cap 15.14 liter
Hydraulic fluid cap 121 liter
Hydraulic fluid cap 83 liter
Fuel cap
Fuel cap -
Fuel cap 83.3 liter
Fuel cap 64 liter
Platform Dimension B
Platform Dimension B 119.13 cm
Platform Dimension B 0.91 m
Platform Dimension B 1.83 m
Platform Dimension A
Platform Dimension A 76.2 cm
Platform Dimension A 2.44 m
Platform Dimension A 0.76 m
Max horizontal reach
Max horizontal reach 6.55 m
Max horizontal reach 1,200 mm
Max horizontal reach 7,520 mm
Max speed forward
Max speed forward 4.83 kph
Max speed forward -
Max speed forward -
Max working height
Max working height 11.16 m
Max working height 15.85 m
Max working height 15.86 m
Operating voltage
Operating voltage 48 V
Operating voltage 12 V
Operating voltage 12
Operating weight
Operating weight 6,427 kg
Operating weight 7,530 kg
Operating weight 6,515 kg
Platform rotation
Platform rotation 180 º
Platform rotation 180 º
Platform rotation 160 degrees
Tire size
Tire size 22x7x17.75
Tire size 12 x 16.5
Tire size 315/55 D20
Engine model
Engine model -
Engine model Deutz D2.9L4
Engine model Deutz D2011
Fuel type
Fuel type -
Fuel type Diesel
Fuel type Diesel
Gradeability
Gradeability -
Gradeability 24 º
Gradeability 24 %
Platform Capacity - Unrestricted
Platform Capacity - Unrestricted 227.02 kg
Platform Capacity - Unrestricted 272 kg
Platform Capacity - Unrestricted 227 kg
Drive Speed - Platform Lowered
Drive Speed - Platform Lowered -
Drive Speed - Platform Lowered 7.2 kph
Drive Speed - Platform Lowered 5 kph
Tire Type
Tire Type Solid non-marking
Tire Type Foam-Filled
Tire Type Rough Terrain
Swing
Swing -
Swing 360 º
Swing 355 degrees
Swing type
Swing type -
Swing type Continuous
Swing type non-continuous
