New holland LB95 Backhoe loaders tech specs

makana img
video play button
Video[1]
Interior [2]
Exterior [4]
Attachments [2]
2004-2009
135.12 liter Fuel cap
294.07 Nm Max torque
70.84 kw Net power
8,500 kg Operating weight
5.7 m Overall Length
2.44 m Overall Width
Show features

Makana rating

Market average

AED 250,000

Starting from

AED 165,000

New holland LB95 Technical specifications

Engine

Alternator supplied amperage

70 Amh

Aspiration

Turbocharged

Displacement

4501.54 cu cm

Max torque

294.07 Nm

Net power

70.84 kw

Number of cylinders

4

Power measured @

2,200 rpm

Torque measured @

1,400 rpm

Backhoe

Backhoe digging depth

4.6 m

Backhoe reach from swivel

5.88 m

Service refill capacities

Cooling fluid cap

24.22 liter

Fuel cap

135.12 liter

Hydraulic fluid cap

118.09 liter

Transmission fluid cap

18.17 liter

General

Engine model

CNH F4GE0454C*D

Max speed forward

38.95 kph

Operating voltage

12 V

Operating weight

8,500 kg

Transmission type

Powershuttle

Refill capacities

Engine oil cap

14 liter

Operating specifications

Extended backhoe digging depth

5.79 m

Extended backhoe dump height

6.49 m

Extended backhoe dump reach

3.32 m

Extended backhoe reach from swivel

6.98 m

Tires

Front tires size (2WD)

12.5 / 70 (10 Ply)

Rear tires size

18.4 / 26

Dimensions

Ground clearance

0.4 m

Height - top of cab

2.9 m

Overall Length

5.7 m

Overall Width

2.44 m

Wheelbase

2.19 m

Loader

Loader digging depth

10.16 cm

Loader dump height

4.48 m

Loader dump reach

0.73 m

Transmission

Max speed reverse

46.51 kph

Number of forward gears

4

Number of reverse gears

4

Hydraulic system

Pump flow cap

151.02 lpm

Pump type

Load Sensing / Flow Compensation

Relief valve pressure

210 bar

View more
Download datasheets
OEM product brochure

New holland LB95 similar models

Highlight differences
New holland LB95.B
LB95.B
New holland LB85
LB85
New holland LB90
LB90
Engine
Alternator supplied amperage 70 Amh
Alternator supplied amperage -
Alternator supplied amperage 70 Amh
Aspiration Turbocharged
Aspiration -
Aspiration Turbocharged
Displacement 4,501.54 cu cm
Displacement -
Displacement 5,001.34 cu cm
Max torque 294.07 Nm
Max torque -
Max torque -
Net power 70.84 kw
Net power -
Net power 73.08 kw
Number of cylinders 4
Number of cylinders -
Number of cylinders -
Power measured @ 2,200 rpm
Power measured @ -
Power measured @ -
Torque measured @ 1,400 rpm
Torque measured @ -
Torque measured @ -
Gross power -
Gross power 63.01 kw
Gross power -
Years 2004-2009
Years 1999-2003
Years 2001-2003
Market Average AED 250,000
Market Average AED 210,000
Market Average AED 230,000
Price AED 165,000
Price AED 130,000
Price AED 150,000
Backhoe
Backhoe digging depth 4.6 m
Backhoe digging depth 4.48 m
Backhoe digging depth 4.24 m
Backhoe reach from swivel 5.88 m
Backhoe reach from swivel 5.55 m
Backhoe reach from swivel 5.55 m
Backhoe dump height -
Backhoe dump height 3.78 m
Backhoe dump height -
Service refill capacities
Cooling fluid cap 24.22 liter
Cooling fluid cap -
Cooling fluid cap 24.6 liter
Fuel cap 135.12 liter
Fuel cap -
Fuel cap 124.91 liter
Hydraulic fluid cap 118.09 liter
Hydraulic fluid cap 128.31 liter
Hydraulic fluid cap 105.98 liter
Transmission fluid cap 18.17 liter
Transmission fluid cap -
Transmission fluid cap -
General
Engine model CNH F4GE0454C*D
Engine model NG Genises 450/NB
Engine model BSD 450T
Max speed forward 38.95 kph
Max speed forward 38.95 kph
Max speed forward 32.19 kph
Operating voltage 12 V
Operating voltage -
Operating voltage 12 V
Operating weight 8,500 kg
Operating weight 7,265 kg
Operating weight 6,674 kg
Transmission type Powershuttle
Transmission type Powershuttle
Transmission type power-reversing/torque converter
Bucket capacity -
Bucket capacity 1.07 cu m
Bucket capacity 1.07 cu m
Bucket width -
Bucket width 227 cm
Bucket width 225 cm
Lifting capacity -
Lifting capacity 2,100.04 kg
Lifting capacity -
Refill capacities
Engine oil cap 14 liter
Engine oil cap -
Engine oil cap 17.03 liter
Operating specifications
Extended backhoe digging depth 5.79 m
Extended backhoe digging depth -
Extended backhoe digging depth 5.46 m
Extended backhoe dump height 6.49 m
Extended backhoe dump height -
Extended backhoe dump height 4.48 m
Extended backhoe dump reach 3.32 m
Extended backhoe dump reach -
Extended backhoe dump reach 2.68 m
Extended backhoe reach from swivel 6.98 m
Extended backhoe reach from swivel -
Extended backhoe reach from swivel 6.68 m
Tires
Front tires size (2WD) 12.5 / 70 (10 Ply)
Front tires size (2WD) -
Front tires size (2WD) -
Rear tires size 18.4 / 26
Rear tires size -
Rear tires size -
Dimensions
Ground clearance 0.4 m
Ground clearance -
Ground clearance 0.4 m
Height - top of cab 2.9 m
Height - top of cab -
Height - top of cab 2.9 m
Overall Length 5.7 m
Overall Length 5.7 m
Overall Length 7.07 m
Overall Width 2.44 m
Overall Width 2.29 m
Overall Width 3.23 m
Wheelbase 2.19 m
Wheelbase -
Wheelbase 2.19 m
Loader
Loader digging depth 10.16 cm
Loader digging depth -
Loader digging depth -
Loader dump height 4.48 m
Loader dump height 3.54 m
Loader dump height 2.74 m
Loader dump reach 0.73 m
Loader dump reach -
Loader dump reach 0.82 m
Breakout force -
Breakout force -
Breakout force 6,323.99 kg
Transmission
Max speed reverse 46.51 kph
Max speed reverse 38.95 kph
Max speed reverse 40.23 kph
Number of forward gears 4
Number of forward gears 4
Number of forward gears 4
Number of reverse gears 4
Number of reverse gears 4
Number of reverse gears 4
Hydraulic system
Pump flow cap 151.02 lpm
Pump flow cap 151.02 lpm
Pump flow cap 151.4 lpm
Pump type Load Sensing / Flow Compensation
Pump type Gear pump
Pump type Tandem gear
Relief valve pressure 210 bar
Relief valve pressure 210 bar
Relief valve pressure 209.94 bar
Attachments
Bucket digging force -
Bucket digging force 5,739.04 kg
Bucket digging force 5,809.62 kg
