Yanmar T175 Compact track loaders tech specs

makana img
video play button
Video[1]
Interior [2]
Exterior [4]
Attachments [2]
2013-2019
3,326.58 cu cm Displacement
0.35 m Ground clearance
2.5 m Loader dump height
0.88 m Loader dump reach
51.01 kw Net power
3,903 kg Operating weight
Show features

Makana rating

Market average

AED 280,000

Starting from

AED 95,000

Yanmar T175 Technical specifications

Engine

Alternator supplied amperage

95 Amh

Displacement

3326.58 cu cm

Engine make

Yanmar

Max torque

242.82 Nm

Net power

51.01 kw

Number of cylinders

4

Loader

Breakout force

2354.01 kg

Loader dump height

2.5 m

Loader dump reach

0.88 m

General

Bucket width

167 cm

Engine model

4TNV98C-NMSL

Max speed forward

12.23 kph

Operating weight

3,903 kg

Service refill capacities

Cooling fluid cap

13.63 liter

Fuel cap

92.35 liter

Hydraulic fluid cap

41.64 liter

Operating specifications

Dump angle

40 º

Rack back angle

50 º

Dimensions

Ground clearance

0.35 m

Length with bucket

3.69 m

Length without Bucket

2.83 m

Max height to hinge pin

324.1 cm

Undercarriage

Ground pressure

0.43 bar

Track gauge

1.34 m

Hydraulic system

Pump flow cap

70.02 lpm

View more
Download datasheets
OEM product brochure

Yanmar T175 similar models

Highlight differences
Yanmar T175-1
T175-1
Cat 249D
249D
Cat 257
257
Engine
Alternator supplied amperage 95 Amh
Alternator supplied amperage -
Alternator supplied amperage -
Displacement 3,326.58 cu cm
Displacement 2,200.79 cu cm
Displacement 2,998.84 cu cm
Engine make Yanmar
Engine make -
Engine make -
Max torque 242.82 Nm
Max torque 46.63 Nm
Max torque -
Net power 51.01 kw
Net power 49.07 kw
Net power 44 kw
Number of cylinders 4
Number of cylinders -
Number of cylinders 4
Bore -
Bore 8.38 cm
Bore 9.91 cm
Gross power -
Gross power 50.04 kw
Gross power 46.98 kw
Stroke -
Stroke 9.91 cm
Stroke 10.16 cm
Aspiration -
Aspiration -
Aspiration Turbocharged
Power measured @ -
Power measured @ -
Power measured @ 2,600 rpm
Years 2013-2019
Years 2016-2019
Years 2014-2019
Market Average AED 280,000
Market Average AED 228,000
Market Average AED 186,000
Price AED 95,000
Price AED 191,000
Price AED 147,000
Loader
Breakout force 2,354.01 kg
Breakout force -
Breakout force -
Loader dump height 2.5 m
Loader dump height 2.25 m
Loader dump height 2.29 m
Loader dump reach 0.88 m
Loader dump reach 0.73 m
Loader dump reach 0.82 m
Breakout force - tilt cylinder -
Breakout force - tilt cylinder 1,797.59 kg
Breakout force - tilt cylinder 1,602.09 kg
Breakout force - lift cylinder -
Breakout force - lift cylinder -
Breakout force - lift cylinder 1,583.04 kg
General
Bucket width 167 cm
Bucket width -
Bucket width -
Engine model 4TNV98C-NMSL
Engine model Cat C2.2 CRDI
Engine model Cat 3034 naturally aspirated
Max speed forward 12.23 kph
Max speed forward -
Max speed forward 12.07 kph
Operating weight 3,903 kg
Operating weight -
Operating weight 3,460 kg
Lifting capacity -
Lifting capacity 1,043.26 kg
Lifting capacity 1,065.94 kg
Max horizontal reach -
Max horizontal reach 1.32 m
Max horizontal reach -
Tipping load -
Tipping load 2,086 kg
Tipping load 2,091 kg
Bucket capacity -
Bucket capacity -
Bucket capacity 0.46 cu m
Service refill capacities
Cooling fluid cap 13.63 liter
Cooling fluid cap 12.11 liter
Cooling fluid cap 9.84 liter
Fuel cap 92.35 liter
Fuel cap 57.15 liter
Fuel cap 90.08 liter
Hydraulic fluid cap 41.64 liter
Hydraulic fluid cap 45.04 liter
Hydraulic fluid cap 55.26 liter
Engine crankcase -
Engine crankcase 9.84 liter
Engine crankcase 6.81 liter
Operating specifications
Dump angle 40 º
Dump angle 48 º
Dump angle -
Rack back angle 50 º
Rack back angle 87 º
Rack back angle 44 º
Air conditioning -
Air conditioning Contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). The system contains 0.81 kg of refrigerant which has a CO2 equivalent of 1.158 metric tonnes.
Air conditioning -
Angle of departure -
Angle of departure 34 º
Angle of departure -
Cab FOPS -
Cab FOPS ISO 3449:2005 Level I
Cab FOPS -
Cab FOPS level II -
Cab FOPS level II ISO 3449:2005 Level II
Cab FOPS level II -
Cab ROPS -
Cab ROPS ISO 3471:2008
Cab ROPS -
Dimensions
Ground clearance 0.35 m
Ground clearance 0.21 m
Ground clearance 0.26 m
Length with bucket 3.69 m
Length with bucket 3.23 m
Length with bucket 3.54 m
Length without Bucket 2.83 m
Length without Bucket 2.52 m
Length without Bucket 2.71 m
Max height to hinge pin 324.1 cm
Max height to hinge pin 21.84 cm
Max height to hinge pin -
Height - top of cab -
Height - top of cab 2.04 m
Height - top of cab 2.04 m
Overall Width -
Overall Width 1.68 m
Overall Width -
Turning radius -
Turning radius 1.46 m
Turning radius 2.29 m
Width over tracks -
Width over tracks -
Width over tracks 1.68 m
Undercarriage
Ground pressure 0.43 bar
Ground pressure 0.32 bar
Ground pressure 0.3 bar
Track gauge 1.34 m
Track gauge -
Track gauge -
Ground contact area -
Ground contact area 28,120.26 cu cm
Ground contact area 29,005.17 cu cm
Track length -
Track length 1.81 m
Track length 1.52 m
Track width -
Track width -
Track width 38.1 cm
Hydraulic system
Pump flow cap 70.02 lpm
Pump flow cap 98.41 lpm
Pump flow cap 57.53 lpm
Relief valve pressure -
Relief valve pressure 230.01 bar
Relief valve pressure -
