John deere 310B vs. John deere 310C Backhoe loaders Comparison

Compare available technical data for Loaders. Find the right details to make your decision easier.

Comparison

Highlight differences

310B

310C

General

Backhoe digging depth

Backhoe digging depth 4.45 m

Backhoe digging depth 4.36 m

Bucket digging force

Bucket digging force 4,354.49 kg

Bucket digging force 5,171.05 kg

Bucket width

Bucket width 227 cm

Bucket width 233 cm

Displacement

Displacement 3,600.25 cu cm

Displacement 4,501.54 cu cm

Loader dump height

Loader dump height 2.68 m

Loader dump height 2.71 m

Loader dump reach

Loader dump reach 0.76 m

Loader dump reach 0.73 m

Max speed forward

Max speed forward 26.55 kph

Max speed forward 36.05 kph

Max torque

Max torque 216.93 Nm

Max torque 300.99 Nm

Operating voltage

Operating voltage 12 V

Operating weight

Operating weight 5,987 kg

Operating weight 5,624 kg

Transmission type

Transmission type Powershuttle

Transmission type -

Wheelbase

Wheelbase 2.1 m

Wheelbase -

Backhoe dump height

Backhoe dump height -

Backhoe dump height 3.32 m

Bucket capacity

Bucket capacity -

Bucket capacity 0.76 cu m

Years

Years 1996-2021

Market Average

Market Average AED 605,000

Price

Price AED 182,000

Backhoe

Backhoe reach from swivel

Backhoe reach from swivel 5.3 m

Backhoe reach from swivel 5.33 m

Engine

Bore

Bore 10.41 cm

Bore 10.67 cm

Engine make

Engine make John Deere

Gross power

Gross power 48.47 kw

Gross power 55.93 kw

Net power

Net power 46.23 kw

Net power -

Number of cylinders

Number of cylinders 4

Power measured @

Power measured @ 2,500 rpm

Power measured @ 2,200 rpm

Stroke

Stroke 11.18 cm

Stroke 12.7 cm

Torque measured @

Torque measured @ 1,300 rpm

Alternator supplied amperage

Alternator supplied amperage -

Alternator supplied amperage 65 Amh

Loader

Breakout force

Breakout force 3,447.31 kg

Breakout force 3,946.26 kg

Service refill capacities

Cooling fluid cap

Cooling fluid cap 11.73 liter

Cooling fluid cap 13.25 liter

Fuel cap

Fuel cap 73.81 liter

Fuel cap 87.06 liter

Hydraulic fluid cap

Hydraulic fluid cap 77.59 liter

Hydraulic fluid cap 79.49 liter

Refill capacities

Engine oil cap

Engine oil cap 8.71 liter

Tires

Front tires size (2WD)

Front tires size (2WD) 7.50/8.00-16

Front tires size (2WD) -

Rear tires size

Rear tires size 16.9-24

Rear tires size -

Dimensions

Front tread range

Front tread range 147.07 cm

Front tread range -

Rear tread range

Rear tread range 165.1 cm

Rear tread range -

Overall Length

Overall Length 7.19 m

Overall Length 7.13 m

Overall Width

Overall Width 2.1 m

Transmission

Max speed reverse

Max speed reverse 30.26 kph

Max speed reverse 32.51 kph

Number of forward gears

Number of forward gears 8

Number of forward gears 4

Number of reverse gears

Number of reverse gears 8

Number of reverse gears 4

Hydraulic system

Pump flow cap

Pump flow cap 143.83 lpm

Pump flow cap 132.48 lpm

Pump type

Pump type Closed center

Pump type Open center

Relief valve pressure

Relief valve pressure 159.96 bar

Relief valve pressure 189.95 bar

Operating specifications

Extended backhoe digging depth

Extended backhoe digging depth -

Extended backhoe digging depth 5.33 m

Extended backhoe dump height

Extended backhoe dump height -

Extended backhoe dump height 3.99 m

Extended backhoe reach from swivel

Extended backhoe reach from swivel -

Extended backhoe reach from swivel 6.43 m

Performance

Looking at performance technical specs and key features the John deere 310B Backhoe loaders excels in terms of engine power at and operating weight compared to other models like the John deere 310C Backhoe loaders.

User rating

Owners operators and fleet managers recommend the John deere 310B Backhoe loaders for its high reliability and endurance in diverse applications. The same can be said about the John deere 310C Backhoe loaders.
