XCMG boom trucks in UAE: 5-ton to 10-ton cranes for different lifting jobs

Boom trucks are useful when the same vehicle needs to carry a load to site and lift it into position. In the UAE, they are used for construction deliveries, generators, industrial equipment, fabricated components, machinery, and general material handling.

Buyers may also search for them as crane trucks, truck-mounted cranes, loader cranes, or, for articulated models, knuckle boom cranes. “HIAB truck” is another common search term, although HIAB is a manufacturer rather than the generic name of the machine.

The XCMG SQS125, SQ8ZK3Q, and SQZ200 cover three different lifting classes. The choice is not only between 5, 8, and 10 tons. Boom type, working radius, lifting height, truck size, and outrigger setup also determine which crane fits the job.

5-ton XCMG SQS125 for lighter lifting jobs

The XCMG SQS125 is the lighter model in this group, with a maximum lifting capacity of 5 tons. It uses a straight telescopic boom with a maximum length of about 11 m and can lift to roughly 12.5 m. This setup can suit regular transport and unloading work involving:

• generators and pumps
• construction materials
• fabricated components
• pallets and site supplies
• smaller machines and attachments

Unlike a knuckle boom crane, the SQS125 extends through telescopic boom sections rather than folding at articulated joints.

For fleets that regularly handle lighter loads, that can provide enough lifting capacity without moving to a larger 8- or 10-ton crane truck.

8-ton XCMG SQ8ZK3Q for heavier site lifting

The XCMG SQ8ZK3Q increases maximum capacity to 8 tons. It also changes the boom design. The SQ8ZK3Q is a folding or knuckle boom crane, allowing the boom to fold into a compact position on the truck and articulate around the load during operation.

Maximum boom length is about 10 m, while maximum lifting height is around 13 m. That additional capacity can make it more suitable for heavier generators, machinery, building materials, mechanical equipment, and other loads that would put a 5-ton crane close to its limits.

The important number, however, is not simply the 8-ton rating. If the load has to be placed several metres away from the truck, the available lifting capacity will be lower.

10-ton XCMG SQZ200 when more capacity is needed

The XCMG SQZ200 moves into the 10-ton class. Like the 8-ton model, it uses a folding knuckle boom configuration. Its boom extends to about 13 m, while maximum lifting height is roughly 15.5 m.

The extra capacity and working range can suit heavier:

• industrial machinery
• generators
• steel components
• construction equipment
• plant and mechanical equipment

The SQZ200 becomes particularly useful when heavier loads are part of normal work rather than occasional lifts.

A 10-ton crane is not automatically the better purchase, though. The larger crane and truck require more space, so buyers should make sure the additional capacity is actually needed for their regular loads.

Boom reach, working radius and truck setup matter too

Two boom trucks with different maximum capacities can perform very differently once the load moves away from the truck.

Maximum boom length tells you how far the boom can physically extend. Working radius tells you how far the load is positioned horizontally from the crane during the lift. That second figure has a major effect on the weight the crane can safely handle.

Why lifting capacity drops as the boom extends

A load creates more overturning force as it moves farther from the crane. This means a truck-mounted crane may handle its maximum rated load close to the truck, but considerably less weight at a longer working radius.

For example, a contractor regularly lifting a 3-ton generator should not simply choose any crane rated above 3 tons. The real question is whether the crane can lift those 3 tons at the radius normally required on site.

When choosing between these XCMG models, check:

• normal load weight
• working radius
• required lifting height
• boom type
• available setup space

The crane load chart should then be used to confirm the permitted capacity for the actual lift.

How outriggers and chassis size affect the lift

A crane truck operates as one system: the crane, truck chassis, outriggers, load, and ground conditions all matter.

Outriggers widen the supported footprint while lifting. As crane capacity increases, the truck and stabilizer setup generally become larger as well. That can be an advantage for heavier work, but it also requires more room around the truck.

For UAE contractors working in industrial yards, warehouses, urban sites, or restricted delivery areas, this matters. A smaller boom truck may be easier to position where space is tight, while a larger crane is justified when heavier loads and longer working radii are common.

Find XCMG boom trucks on Makana

Buyers can explore XCMG boom truck cranes on Makana, including the 5-ton SQS125, 8-ton SQ8ZK3Q, and 10-ton SQZ200. Makana also provides XCMG boom truck crane technical specifications, helping buyers review lifting capacity, boom dimensions, lifting height, and truck configuration before choosing a model. Depending on the available machine, buyers can also access:

• 75+ point inspection reports
• operational videos
• detailed photography
• Ultra-HD 3D and 360° views
• remote or in-person inspection options

Makana can also support UAE delivery and international shipping. If the required truck-mounted crane, knuckle boom model, or lifting capacity is not currently available, the machinery procurement service can help source the required configuration.

FAQs

Is a boom truck the same as a HIAB truck?

HIAB is a crane manufacturer, not the generic name of the equipment. However, “HIAB truck” and “HIAB crane” are commonly used search terms for truck-mounted lifting equipment.

What is the difference between a straight boom and a knuckle boom crane?

A straight boom extends through telescopic sections. A knuckle boom uses articulated sections that fold together, giving the crane a more compact stored position and additional flexibility around the load.

Is the XCMG SQS125 a knuckle boom crane?

No. The XCMG SQS125 uses a straight telescopic boom and has a maximum lifting capacity of 5 tons.

How much can the XCMG SQ8ZK3Q lift?

The XCMG SQ8ZK3Q has a maximum lifting capacity of 8 tons. Its available lifting capacity decreases as the working radius increases.

How much can the XCMG SQZ200 lift?

The XCMG SQZ200 has a maximum lifting capacity of 10 tons, with about 13 m maximum boom length and roughly 15.5 m maximum lifting height.

Why does boom truck crane capacity decrease at longer radius?

Moving the load farther from the crane increases the overturning force. The permitted lifting capacity therefore decreases as the working radius increases.

Where can I buy XCMG boom trucks in the UAE?

Makana lists XCMG boom truck cranes in the UAE and provides model specifications, inspection information, operational videos, detailed imagery, viewing options, and delivery or shipping support depending on the machine.
