Bomag BW 190 AD-HF4 Tandem rollers 2011 SRC-014

This used 2011 Bomag BW 190 AD-HF4 tandem roller is an 11.5-ton double drum roller delivering 126 kN compaction force, about 12.8 tons, built for asphalt finishing, surface compaction, and final rolling work on roads, parking areas, and other paved jobs where even drum contact and consistent finish quality matter. With 2,000 mm, 79 in, drums and a drum-driven setup, it is suited to steady paving passes and controlled surface finishing on medium-width asphalt work.

This Germany-made unit comes with an open operator station and dual controls, using a rotatable and laterally sliding seat with two steering wheels for easier operation in either rolling direction. Power comes from a 4-cylinder 4.0-liter Deutz TCD2012 L04 diesel engine rated at 134 hp, while the compaction setup includes articulated steering with crab steer capability, left and right 170 mm, up to 70 Hz frequency, and static linear load of about 28.3 to 31 kg/cm front and rear. It also has a 1,000 L water system volume, carries a 2011 US EPA label, and shows 2,720 hours on the meter.

Highlights:

• 11.5-ton tandem roller
• 126 kN compaction force, about 12.8 tons
• 2,000 mm, 79 in, double drums
• 134 hp Deutz TCD2012 L04 4.0-liter diesel engine
• Open operator station with dual controls
• 1,000 L water system volume
