Cat D6D LGP vs. Cat D8T Crawler dozers Comparison

Compare available technical data for Bulldozers. Find the right details to make your decision easier.

Comparison

Highlight differences

Cat D6 Crawler dozers

D6D LGP

Cat D8 crawler dozers

D8T

General

Engine model

Engine model 3306

Engine model C15 ACERT

Operating weight

Operating weight 17,373 kg

Operating weight 40,000 kg

Blade capacity

Blade capacity 3.13 cu m

Blade capacity 8.72 cu m

Max speed forward

Max speed forward 10.94 km/h

Max speed forward 10.62 km/h

Drive type

Drive type Powershift

Drive type Hydrostatic

Engine power

Engine power -

Engine power 240 hp

Operating voltage

Operating voltage -

Operating voltage 24 V

Years

Years 2005-2018

Years 2018-2024

Market Average

Market Average AED 435,000

Market Average AED 1,750,000

Price

Price AED 410,000

Price AED 1,300,000

Engine

Displacement

Displacement 10,500.85 cm3

Displacement 15,207.23 cm3

Gross power

Gross power 104.4 kw

Gross power 258.76 kw

Aspiration

Aspiration -

Aspiration Natural

Power measured @

Power measured @ -

Power measured @ 2,000 rpm

Max torque

Max torque -

Max torque 3,100 Nm

Alternator supplied amperage

Alternator supplied amperage -

Alternator supplied amperage 100 Amh

Number of cylinders

Number of cylinders -

Number of cylinders 6

Net power

Net power -

Net power 232.66 kw

Bore

Bore -

Bore 110 cm

Stroke

Stroke -

Stroke 90 cm

Operational specifications

Blade width

Blade width 3 m

Undercarriage

Ground contact area

Ground contact area 133,351.67 cu cm

Ground contact area 91,013.95 cu cm

Ground pressure

Ground pressure 0.32 bar

Ground pressure 3,120 bar

Number of track rollers per side

Number of track rollers per side 7

Number of track rollers per side 8

Track width

Track width 91.19 mm

Track width 61.21 mm

Track gauge

Track gauge 2.13 m

Track gauge 2.1 m

Number of shoes per side

Number of shoes per side -

Number of shoes per side 44

Track pitch

Track pitch -

Track pitch 21.59 cm

Tracks length

Tracks length -

Tracks length 3 m

Track length

Track length -

Track length 3.1 m

Dimensions

Height - top of cab

Height - top of cab 2.93 m

Height - top of cab 3.6 m

Length with blade

Length with blade 5.18 m

Length with blade 6.1 m

Length without blade

Length without blade 3.96 m

Length without blade 4.63 m

Ground clearance

Ground clearance 0.34 m

Ground clearance 0.64 m

Width over tracks

Width over tracks 3.05 m

Width over tracks 2.71 m

Blade height

Blade height -

Blade height 1.65 cm

Service refill capacities

Fuel cap

Fuel cap 295.23 liters

Fuel cap 643.45 liters

Cooling fluid cap

Cooling fluid cap -

Cooling fluid cap 76.84 liters

Hydraulic fluid cap

Hydraulic fluid cap -

Hydraulic fluid cap 74.94 liters

Transmission

Max speed reverse

Max speed reverse 13.04 kph

Max speed reverse 14.16 kph

Number of reverse gears

Number of reverse gears 3

Number of forward gears

Number of forward gears 3

Hydraulic system

Pump flow cap

Pump flow cap -

Pump flow cap 276.31

Relief valve pressure

Relief valve pressure -

Relief valve pressure 393 psi

Pump type

Pump type -

Pump type piston-type, variable displacement

Refill capacities

Final drives fluid cap

Final drives fluid cap -

Final drives fluid cap 12.49 liters

Engine oil cap

Engine oil cap -

Engine oil cap 37.85 liters

Blades

Blade angle

Blade angle -

Blade angle 40 degrees

Performance

Looking at performance technical specs and key features the Cat D6D LGP Crawler dozers excels in terms of engine power at and operating weight 17373 compared to other models like the Cat D8T Crawler dozers.

User rating

Owners operators and fleet managers recommend the Cat D6D LGP Crawler dozers for its high reliability and endurance in diverse applications. The same can be said about the Cat D8T Crawler dozers.
