Sinoboom AB15J Boom lifts
CE Certified
GCC specsReference number
BLA-002
Brand
Sinoboom
Model
AB15J
Year
2024
Working hours
917 hrs
Serial number
0402101274
Country of manufacture
China
Operating weight
7.28 ton
Engine model
2.2-liter 4-cylinder Yanmar 4TNV88-ZCDCSI
Engine power
47.00 hp
Drive type
4WD / 2WS
Platform rotation
355 º
Gradeability
40 %
Max working height
16.70 m
Personnel load cap
2 with 90 kg tools
Fuel type
Diesel
Max platform height
14.70 m
Max horizontal reach
8.50 m
Up and over height
7.20 m
Platform capacity
250.00 kg
Max allowable wind speed
12.50 M/s
Traction force
400.00 N
Hydraulic pressure
28.00 MPa
Operating voltage
12 V
Fuel capacity
70.00 liters
Tire fill/type
12-ply nylon tubeless
Tires size
315/55D20NHS
Condition
Used
With our detailed inspection reports backed by Makana® equipment certification you can be sure that what you see in the report is what you get.
This used 2024 Sinoboom AB15J diesel articulated boom lift, officially designated as the GTZZ15J mobile elevating work platform, offers a 16.7 m maximum working height with 8.5 m horizontal reach, making it a practical MEWP for façade access, steelwork, maintenance, installation, and other elevated tasks that need both height and outreach. With a 14.7 m platform height, 7.2 m up-and-over height, and a 250 kg platform capacity for two operators with tools, it suits jobs where the machine has to reach over obstacles and still give a stable working position.
This unit is powered by a 2.2-liter 4-cylinder Yanmar 4TNV88-ZCDCSI diesel engine rated at 47 hp, and comes with 40% gradeability when stowed, 355° rotation, 28 MPa hydraulic pressure, a 12 V electrical system, 400 N maximum traction force, and a maximum allowable wind speed of 12.5 m/s. With an operating weight of 7,280 kg and only 917 hours on the meter, it presents in like-new condition for site access, maintenance, and elevated support work.
Highlights:
- 16.7 m maximum working height
- 8.5 m horizontal reach
- 14.7 m platform height with 7.2 m up-and-over height
- 250 kg platform capacity for two operators with tools
- 47 hp Yanmar 4TNV88-ZCDCSI diesel engine
- Like-new condition with 917 hours
