Cat D5E Crawler dozers research
2025
Cat D5E Crawler dozers Technical specifications
General
Engine model
3306
Operating weight
11,702 kg
Max speed forward
11.1 kph
Engine
Displacement
10500 cu cm
Dimensions
Ground clearance
0.3 m
Service refill capacities
Fuel cap
295.23 liters
Undercarriage
Number of track rollers per side
6
Track gauge
1.52 m
Transmission
Max speed reverse
10.14 kph
Number of reverse gears
6
Number of forward gears
6
Download datasheets
Cat D5E vs Cat D5G LGP
Cat D5E Crawler dozers
Cat D5G LGP Crawler dozers
Engine model
3306
3046T
Operating weight
11,702 kg
9,268 kg
Max speed forward
11.1 kph
9.01 kph
Blade capacity
-
2.37 m3
Market Average
AED 125,000
AED 125,000
price
-
-
Years
2025
2025
Displacement
10,500 cu cm
4,998 cu cm
Gross power
-
73.83 kw
Alternator supplied amperage
-
120 Amh
Operating voltage
-
12 V
Net power
-
67.11 kw
Ground clearance
0.3 m
0.4 m
Length with blade
-
4.27 m
Length without blade
-
3.2 m
Blade height
-
1.03 mm
Width over tracks
-
2.41 m
Fuel cap
295.23 liters
183.95 liters
Cooling fluid cap
-
16.28 liters
Hydraulic fluid cap
-
45.42 liters
Number of track rollers per side
6
7
Track gauge
1.52 m
1.74 m
Ground contact area
-
77,691.24 cm3
Number of shoes per side
-
39
Tracks length
-
2 m
Ground pressure
-
0.3 bar
Track width
-
66.04 cm
Max speed reverse
10.14 kph
9.66 kph
Number of reverse gears
6
1
Number of forward gears
6
1
Drive type
-
Hydrostatic
Blade width
-
3 mm
Final drives fluid cap
-
21.57 liters
Engine oil cap
-
12.87 liters
Pump flow cap
-
60.94 lpm
Relief valve pressure
-
199.94 bar
Blade angle
-
25 degrees
