Genie Z-45/25J Bi Boom lifts research
2025
Genie Z-45/25J Bi Boom lifts Technical specifications
General
Operating weight
7,394 kg
Max speed forward
4.83 kph
Max horizontal reach
7.65 m
Max working height
15.94 m
Transport dimensions
Transport width
1 m
Dimensions
Ground clearance
0.24 m
Turning radius
4.27 mm
Wheelbase
2.04 mm
Stowed height
2.01 m
Engine
Gross power
8.95 kw
Operating voltage
48 V
Number of batteries
8
Battery amperage
350 Amh
Service refill capacities
Fuel cap
34.44 liters
Hydraulic fluid cap
30.28 liters
Operating specifications
Personnel load cap
227.02 kg
Max platform height
13.93 m
Inner platform width
76.2 cm
Inner platform length
183.13 cm
Platform rotation
180 degrees
Tires
Tires size
9x14.5
Tire fill/type
Foam
Download datasheets
Genie Z-45/25J Bi vs Genie Z-45/25J RT
Genie Z-45/25J Bi Boom lifts
Genie Z-45/25J RT Boom lifts
Operating weight
7,394 kg
6,486 kg
Max speed forward
4.83 kph
8.05 kph
Max horizontal reach
7.65 m
7.65 m
Max working height
15.94 m
16.09 m
Engine model
-
DSG-423
Market Average
AED 125,000
AED 125,000
price
-
-
Years
2025
2025
Transport width
1 m
2 m
Ground clearance
0.24 m
0.39 m
Turning radius
4.27 mm
4.51 mm
Wheelbase
2.04 mm
2.04 mm
Stowed height
2.01 m
2.13 m
Gross power
8.95 kw
55.93 kw
Operating voltage
48 V
-
Number of batteries
8
-
Battery amperage
350 Amh
-
Fuel cap
34.44 liters
64.72 liters
Hydraulic fluid cap
30.28 liters
90.84 liters
Personnel load cap
227.02 kg
227.02 kg
Max platform height
13.93 m
14.08 m
Inner platform width
76.2 cm
76.2 cm
Inner platform length
183.13 cm
183.13 cm
Platform rotation
180 degrees
180 degrees
Tires size
9x14.5
355/55 D625
Tire fill/type
Foam
-
