Cat 287B Compact track loaders research

makana img
2025

Cat 287B Compact track loaders Technical specifications

General

Engine model

Cat 3044C DIT

Operating weight

4,660 kg

Max speed forward

11.27 kph

Max horizontal reach

1.38 m

Engine

Displacement

3293 cu cm

Aspiration

Turbocharged

Gross power

61.15 kw

Alternator supplied amperage

90 Amh

Operating voltage

12 V

Net power

58.17 kw

Bore

9.4 cm

Stroke

11.94 cm

Transport dimensions

Transport width

1 m

Operational specifications

Tipping angle

7,198 degrees

Undercarriage

Ground contact area

47499.65 cu cm

Tracks length

1 m

Ground pressure

0.26 bar

Dimensions

Ground clearance

0.28 m

Width over tracks

1.98 m

Length with bucket

3.72 m

Max height to hinge pin

21.84 cm

Turning radius

1.62 m

Hydraulic system

Pump flow cap

124.91 lpm

Relief valve pressure

279.99 bar

Pump type

High Flow XPS

Loader

Loader lift cap

1632.03 kg

Loader dump height

2.41 m

Loader dump reach

0.85 m

Tipping load

3265.87 kg

Service refill capacities

Cooling fluid cap

10.22 liters

Fuel cap

110.14 liters

Hydraulic fluid cap

51.1 liters

Engine crankcase

9.84 liters

Refill capacities

Engine oil cap

10.22 liters

View more

Cat 287B vs Cat 287C

Cat 287B Compact track loaders

Cat 287C Compact track loaders

General
Engine model
Cat 3044C DIT
Cat C3.4 DIT
Operating weight
4,660 kg
4,516 kg
Max speed forward
11.27 kph
14.97 kph
Max horizontal reach
1.38 m
1.29 m
Market Average
AED 125,000
AED 125,000
price
-
-
Years
2025
2025
Engine
Displacement
3,293 cu cm
3,293 cu cm
Aspiration
Turbocharged
-
Gross power
61.15 kw
62.64 kw
Alternator supplied amperage
90 Amh
90 Amh
Operating voltage
12 V
12 V
Net power
58.17 kw
61.15 kw
Bore
9.4 cm
9.4 cm
Stroke
11.94 cm
11.94 cm
Number of cylinders
-
4
Transport dimensions
Transport width
1 m
1 m
Operational specifications
Tipping angle
7,198 degrees
7,743 degrees
Undercarriage
Ground contact area
47,499.65 cu cm
41,656.01 cu cm
Tracks length
1 m
1 m
Ground pressure
0.26 bar
0.28 bar
Dimensions
Ground clearance
0.28 m
0.22 m
Width over tracks
1.98 m
1.98 m
Length with bucket
3.72 m
3.72 m
Max height to hinge pin
21.84 cm
19.81 cm
Turning radius
1.62 m
1.63 m
Hydraulic system
Pump flow cap
124.91 lpm
124.91 lpm
Relief valve pressure
279.99 bar
279.99 bar
Pump type
High Flow XPS
High Flow XPS
Loader
Loader lift cap
1,632.03 kg
1,723.65 kg
Loader dump height
2.41 m
2.47 m
Loader dump reach
0.85 m
0.79 m
Tipping load
3,265.87 kg
3,512.17 kg
Service refill capacities
Cooling fluid cap
10.22 liters
14 liters
Fuel cap
110.14 liters
98.03 liters
Hydraulic fluid cap
51.1 liters
57.15 liters
Engine crankcase
9.84 liters
9.84 liters
Refill capacities
Engine oil cap
10.22 liters
10.22 liters
Operating specifications
Dump angle
-
50 degrees
Rack back angle
-
85 degrees
Angle of departure
-
42 degrees
