ASV PT-70 Compact track loaders research

Engine model

804C-33T

Operating weight

3,578 kg

Bucket capacity

0.31 cu m

Max speed forward

11.27 kph

Displacement

3310 cu cm

Aspiration

Turbocharged

Gross power

52.95 kw

Max torque

234.55 Nm

Alternator supplied amperage

90 Amh

Operating voltage

12 V

Number of cylinders

4

Transport width

1 m

Tipping angle

5,500 degrees

Ground contact area

34904.52 cu cm

Tracks length

1 m

Ground pressure

0.26 bar

Number of track rollers per side

14

Track width

38.1 cm

Length without Bucket

2.87 m

Ground clearance

0.38 m

Width over tracks

1.68 m

Length with bucket

3.6 m

Pump flow cap

113.55 lpm

Relief valve pressure

206.84 bar

Loader lift cap

2494.76 kg

Loader dump height

2.5 m

Loader dump reach

0.52 m

Cooling fluid cap

11.36 liters

Fuel cap

68.13 liters

Hydraulic fluid cap

79.49 liters

Engine oil cap

34.07 liters
