ASV PT-30 Compact track loaders research

Engine model

403C-15

Operating weight

1,499 kg

Max speed forward

9.66 kph

Displacement

1507 cu cm

Aspiration

Naturally aspirated

Gross power

25.35 kw

Max torque

87.31 Nm

Alternator supplied amperage

65 Amh

Operating voltage

12 V

Transport width

1 m

Height - top of cab

1.83 m

Length without Bucket

2.32 m

Ground clearance

0.25 m

Width over tracks

1.22 m

Length with bucket

2.87 m

Tipping angle

1,600 degrees

Ground contact area

19385.94 cu cm

Tracks length

1 m

Ground pressure

0.19 bar

Number of track rollers per side

12

Track width

27.94 cm

Pump flow cap

37.85 lpm

Relief valve pressure

206.84 bar

Loader lift cap

861.83 kg

Cooling fluid cap

5.68 liters

Fuel cap

37.85 liters

Hydraulic fluid cap

30.28 liters

Engine oil cap

15.14 liters
